Seal Pile

TOLERANCES SP

SP: Seal Pile

This pile is standard product produced with 100 % Polypropylene.

a BASE WIDTH

+ 0,10 mm 4,8 Max: 4,90 mm Min:4,60
+ 0,20 mm 6,9 Max: 7 mm Min:6,70

bPILE HEIGHT

+ 0,25 mm – 0,15 mm
If the height of the pile is superior to 6,50 mm
+ 4% -2,5%

c BASE THICKNESS

0,80 % ± 0,15 %

d PILE WIDTH

4,8 (2P y 3P): 1,98mm ±0,12mm Max: 2,10 Min: 1,86mm
6,9 (3P y 4P): 2,90mm ±0,30mm Max: 3,20 Min: 2,60mm
